Branson
$ 17,398.00

Branson 2205 Compact Tractor w/ Hard Cab & Front Loader

OVERVIEW

These tractors are well built and easy to maintain.


FEATURES

• Clean, Quiet and Powerful Engine
• Tier 4 Certified With No DPF Filter
• Hydrostatic Power Steering
• Dual Pedal Foot Controls
• Quick Attach Loader Bucket
• Mower And Backhoe (Option)

SPECIFICATIONS

General
Drive System
Steering Hydrostatic
Clutch N/A
Battery 12V
Brake Wet Disc
Engine
Model 3TNM74F
Type  Natural Aspiration
Combustion System
Aspiration
HP 21.5
RPMs 3200
No. of Cylinders 3
Bore x Stroke
Displacement 60.6 cc
Compression Ratio
Air Cleaner Type Single Dry
Capacities
Fuel Capacity 6.6 gal
Cooling System 3.7 gal
Crankcase [with filter] 2.1 gal
Trans & Hyd. System 3.6 gal
Front Axle 2.6 gal
Tires
Front Tread 18x8.5-10-4
Rear Tread 26x12-12-4
Dimensions
Overall Length With 3P 94.2 in
Overall Width 44.5 in
Height to Top of ROPS 86.6 in
Wheelbase 53.1 in
Min. Ground Clearance 8.3 in
Min. Tum Radius, w/o Brakes 86.6
Rollover Protection Standard ROPS
Weight 1433 lbs
Transmission
Type HST
Number of Speeds 2 Range
Max. Travel Speed 7.8 mph
Brakes Wet Disc
Steering Hydrostatic
PTO
Type  Independent PTO
PTO Control Electric/Hydro
PTO Mid-Option 2500 RPM
PTO rear 540 RPM
PTO Shaft Diameter 1 3/8 in
Hydraulic System
Pump Type Single Gear Pump with Flow Divider
Implement Pump Cap. 4.17 GPM
Steering Pump Cap. 6.3 GPM
3-Point Hitch Category 1
Hitch Lift Capacity 1100 lbs.
At 24 Inches Behind Link Ends 679 lbs.
Lift Control Type Position






SKU:2205
