Sale!
$ 8,799.00 $ 9,841.00

With a silent, yet powerful 5KW motor, a maintenance-free battery system, and an industry-leading 40 mile range, the EV5 has appeal for farmers, ranchers, campers, and homeowners

Highlights & Features

Built for durability and ease of maintenance

  • Maintenance-free, sealed AGM batteries
  • No need to take unit into dealership to service every 2-3 months, simply charge battery once every month
  • 35-40 miles on one charge
  • 2 year battery limited warranty

Built for Outdoors

  • 4 wheel independent suspension
  • Low noise levels
  • 10" ground clearance

Built for farm, ranch, & ground maintenance

  • Rack and pinion steering
  • Instant torque equivalent to 13 HP (7HP rated)
  • Towing capacity of 450 l bs
  • Passenger capacity of 770 l bs
  • Rear seat convertible to deck
  • Optional tilting dump bed kit, 2” receiver hitch

Built for Family & Transportation

  • Brushless DC motor is highly efficient and durable
  • Top speed 25 MPH
  • 3 year motor and controller warranty
  • Seats up to 4
  • Extended legroom

Specifications

Motor

Motor
60V Brushless DC motor
Power Source
DC 60V
Gear Selection
F-N-R
Drivetrain
Shaft Drive; 2WD
Battery
5x12V, 100A
Max Torque
9.5 lb.-ft.

Dimensions

Bed Dimension
43.4 in x 26.4 in
Front Tire
24 x 8-12
Ground Clearance
10 in
Length x Width x Height
105 in x 55 in x 74 in
Passenger Capacity
770 lbs
Rear Tire
24 x 8-12
Seat Height
33 in
Wheelbase
63.75 in


Suspension

Front Suspension
McPherson Independent
Rear Suspension
Independent Double A-Arm


Brakes

Front Brake
Hydraulic Disc
Rear Brake
Hydraulic Disc


Other

Optional Colors
Black, Camo, Carbon, Orange, Olive Drab Green, White
Standard Colors
Red, Blue






SKU:EV5GVX
